Logitech Tap Scheduler - Graphite

(0) No Reviews yet
SKU: LOG-952-000091-014


Logitech Tap Scheduler - Graphite

Scheduling Panel for Meeting Rooms

  • 10.1” touchscreen: Easily read details and reserve a room on the spacious and responsive touchscreen.
  • Anti-fingerprint: Oleophobic coating resists fingerprints for legibility.
  • Durable build: Components are built to last, with the screen sealed to protect parts and withstand regular cleaning.
  • Availability lighting: Green or red status lights indicate availability from a distance without distracting from the surroundings.
  • Flat angle for accessibility: Tap Scheduler is mounted flat against the wall for easy reading from a variety of heights.
  • Low profile install: With no offset required, Tap Scheduler mounts flush to the wall for a sleek, unobtrusive presence.

Make it easy to find and claim the right meeting space with Tap Scheduler. This purposebuilt scheduling panel integrates with solutions from Microsoft Teams, Zoom Rooms, Robin, and Meetio to signal availability from a distance, and provide meeting details up close.

Make the most out of every meeting space by helping workers easily find the right room — whether that’s checking room details to make sure it’s the right place, or reserving a room for impromptu or scheduled meetings.

With a spacious screen and sleek, unobtrusive profile, Tap Scheduler is designed for easy viewing and usability. Complete with glass, mullion, and wall mounts, Tap Scheduler can be conveniently installed outside any room. Its built-in cable management hides cables for a clean and professional look. Count on Tap Scheduler for reliable performance with durable components that are built to last.

  • Size: 10.1” (256.54 mm) diagonal
  • IPS (In-Plane Switching)
  • LCD Panel with LED Backlighting
  • Resolution: 1280 x 800 resolution
  • Touch: Capacitive, 10 points multi-touch
  • Brightness: 400 nits
  • Contrast: 1000:1
  • Anti Fingerprint: Oleophobic coating
  • Viewing angle: 85 degrees (U/D/L/R)
  • Position angle: 0 degrees (flat on mounting surface)
  • Integrated accelerometer
  • Integrated ambient light sensor
  • 100 mm x 100 mm VESA FDMI
  • Cable exits: horizontal / vertical / center
  • Logitech Tap Scheduler integrates with leading room scheduling solutions as a
  • Microsoft Teams Panel
  • Zoom Rooms Scheduling Display
  • Robin-Powered scheduling panel
  • AppSpace
  • Meetio scheduling panel
  • See www.logitech.com/support/tapscheduler-compatibility for the latest certification and compatibility information.
  • Logitech CollabOS platform
  • Logitech Sync Remote Management
Power and Cables
  • Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device. *Requires PoE enabled network or PoE Injector and ethernet cable (Not included)
  • Ethernet: 10/100 Mbps
  • WiFi: 802.11a/b/g/n/ac
  • Bluetooth 5.0 (inactive, reserved for future use)
  • Operating Temperature: 0 to 40°C
  • Storage Temperature: -40 to 70°C
  • Humidity: 10-95%
  • Full Disk Encryption: AES-128
  • Data Encryption: Symmetric Keys, PKI
  • Device Identity: Protected by device attestation
  • Key Protection: Arm TrustZone
  • Logitech Tap Scheduler
  • Multi-surface mount (glass/drywall)
  • Corner mount accessory
  • Mullion mount
  • Mounting hardware
  • Documentation
